Core / Mould Coatings

It is Water Based mixed refractory coating for cores / moulds made by shell process.

 Download PDF for More Details

Specifications

Product Name	Form	Filler/ Carrier	Physical Properties	Application Methods
BP COAT 1551	Liquid	Mixed Refractory filler/ Water	Baume - 50-65 Sp.Gr.- 1.30-1.45 Solids- 45 +/- 3	Dipping, Brushing Spraying
BP COAT 1552	Liquid	Alumina, Special Grade Alu. Silicate/ Water	Baume – 80-115 Sp.Gr.- 1.45-1.65 Solids- 53 +/- 3	Dipping, Brushing Spraying
BP COAT 1553	Liquid	Alu. Silicate/ Water	Baume - 80-120 Sp.Gr.- 1.5-1.6 Solids- 57 +/- 3	Dipping, Brushing Spraying
BP COAT 1554	Liquid	Special Grade Alu. Silicate/ Water	Baume – 80-110 Sp.Gr.- 1.45-1.55 Solids- 52 +/- 3	Dipping, Brushing Spraying
BP COAT 1555	Thixo- Tropic Liquid	Zircon/ Water	Baume - 95-115 Sp.Gr.- 2.15-2.30 Visc. - NCF Solids- 72 +/- 5	Brushing.
BP COAT 1556	Liquid	Graphite/ Water	Baume - 65 – 85 Sp. Gr- 1.30-1.40 Visc. – NCF Solids- 48+/-3	Brushing, Dipping
BP COAT 1557	Liquid	High Grade aluminium silicate/ Water	Baume - 80 – 110 Sp. Gr- 1.30-1.40 Visc. – NCF Solids- 45+/-3	Dipping
BP COAT 1558	Liquid	Aluminium silicate/ Water	Baume - 65 – 95 Sp. Gr- 1.40-1.60 Visc. – NCF Solids- 52+/-3	Dipping
BP COAT 1559	Liquid	Aluminium Silicate/ Water	Baume - 65 – 95 Sp. Gr- 1.35-1.55 Visc. – NCF Solids- 52+/-3	Dipping

This is a general purpose ready to use Zircon alcohol based coating suitable for all types of Binder Backgrounds.

 Download PDF for More Details

Specifications

Product Name	Form	Filler/ Carrier	Physical Properties	Application Methods
BP COAT 2014	Liquid	Zircon/ Solvent	Baume - 55-70 Sp.Gr.- 1.50-1.65 Visc. - NCF Solids- 65 +/- 5	Spraying, Brushing and Ignite
BP COAT 2015	Liquid	Graphite/ Solvent	Baume - N/A Sp.Gr.- 1.0- 1.10 Visc. - 12-17Sec Solids- 35 +/- 3	Spraying, Brushing and Ignite
BP COAT 2016	Liquid	Al. Silicate/ Solvent	Baume- 30-50 Sp.Gr.- 1.15-1.35 Visc. - NCF Solids- 50 +/- 3	Dipping, Brushing And spraying
BP COAT 2017	Liquid	Blend of organic solvent	Sp. Gr.- 0.780-0.790 RI - 1.330-1.340	To adjust Consistency of Product
BP COAT 2018	Liquid	Graphite/ Sp.grade carbon/ Solvent	Baume - N/A Sp.Gr.- 1.0- 1.10 Visc. - 12-17Sec Solids- 35 +/- 3	Spraying, Brushing and Ignite.
BP COAT 2019	Liquid	Graphite/ Solvent	Baume - N/A Sp.Gr.- 0.97- 1.04 Visc. - 12-17Sec Solids- 32 +/- 3	Spraying, Brushing, Dipping and Ignite
BP COAT 2020	Liquid	Graphite/ Aluminium silicate/ Solvent	Baume - N/A Sp.Gr.- 1.0- 1.10 Visc. - 12-17Sec Solids- 35 +/- 3	Spraying, Brushing and Ignite
BP COAT 2021	Liquid	Magnesite / Solvent	Baume - 50+1-5 Visc. • 13-20 Sec Sp. Gr. -1.45 +1-0.05 Solids - 63 +/- 5	Spraying, Brushing and Ignite
BP COAT 2022	Liquid	Aluminium silicate; Zircon / Solvent	Baume - 70.100 Visc. - NCF Sp. Gr. -1.53.1.70 Solids - 65 +/- 5	Brushing
BP COAT 2023	Liquid	SilicaFlour; Magnesium oxide / Solvent	Baume - 45 - 60 Visc. • NCF Sp. Gr. -1.15.1.35 Solids - 50 +/- 5	Brushing - Spraying

BP COAT 3001 :
BP COAT 3001 is a refractory Graphite - water based coating; very much suitable to be used as runner coating in centrifugal casting. BP COAT 3001 offers good brush ability with suitable diluted consistency. It gives a good adequate bond to the metal portion from where the liquid metal flows towards centrifugal casting. It also acts as a barrier between hot metal and the metallic runner body not allowed hot metal to stick to the runner and gives good peel off.

Specifications

Product Name	Form	Filler/ Carrier	Physical Properties	Application Methods	Packing
BP COAT 3001	Liquid	Graphite/ Water	Baume - 40-70 Sp.Gr.- 1.10- 1.25 Visc. - N/A Solids- 30 +/- 3	Brushing.	20 Kg
